BOMAC
10079
40x1300 mm
ELECTRO-MECHANICAL CLAMPING
Max drilling capacity 40 mm
Tapping capacity mm 22
Distance spindle axis/column min/max mm 300-1300
Head travel on the arm 1000 mm
Column diameter 300 mm
Spindle connection CM 4
Spindle stroke 280 mm...
For clamping different materials for the optionally three different clamping inserts are available. The use of teeth results in a high surface pressure whereby maximum holding forces are achieved. In the case of wear of the Mastergrip clamping claws ...
X Table travel: 4.000 mm
Y Headstock vertical travel: 3.000 mm
Z, Column in spindle direction: 2.000 mm
W, spindle stroke: 900 mm
Spindle diameter: 150 mm
Spindle diameter: ISO 50
Spindle speed: 4 - 3.000 rpm
Spindle motor, 2 steps, ZF: 41/56 kW
Rota...
Gripper jaws can be a great way of getting round part movement in roughing operations, this is by use of teeth in the jaw which bite into the material. This biting can also be a great way to get round problems using black bar or other rough material....
