X Axis: 1000 mmY Axis: 800mmZ Axis: 810mmTable Length: 630mmTable Width: 630mmMax. part weight: 1200kgTool Slots: 150Max Spindle Speed: 10,000 RPMSpindle Motor Power: 30 kWMachine Dimensions: 6000 x 3460 x 3290mm (L x W x H)Weight: 24000 kgFMS Dimens...
HARTFORD
08964
CNC FANUC 21i-MB
TABLE:
Working surface mm 1150x600
T-slot (DimensionsxNumberxpitch) mm 18x5x120
Max table load Kg 700
STROKES:
Longitudinal stroke axis X mm 1000
Cross stroke axis Y mm 600
Verticale stroke Z mm 630
Distance from spind...
Specifications: CNC:NUM 760 Centre distance 5 000 mm Swing over bed 1 500 mm Swing over saddle 900 mm Bed width 970 mm Max load between centres 6 000 kg Max load on chuck 3 000 kg Spindle bore 151 mm Main motor power 45 k...
