CMT
09188
CNC ECS 2400
Height center mm 400
Distance between center mm 2000
Swing diameter over the bed mm 815
Swing diameter over the cross slide mm 485
Axis Z stroke mm 2000
Axis X stroke mm 450
Spindle nose ASA 11''
Spindle bore mm 137
Spindle mot...
Chip conveyor (chain type) Roof with door opening for overhead crane load Wash down EMC + Safety module for CE regulations Full specifications of different controls and powers available on request. Options also on request. ...
Cutting Length 3060mm. Cutting Capacity (45 Kg/mm2) 10mm. Cutting Capacity (70 Kg/mm2) 6mm. Cutting Angles 2. Max Stroke Per Minute 12. No. of Hold Downs 17. Main Motor 22kW. Backgauge Motor 0.37kW. Nominal Power (excluding options) 23.9kW. Backgauge...
Table diameter: 2.000 mm
Max. Swing up to a height of 580 mm: 2.600 mm
Max. Swing: 2.300 mm
Turning Heigth: 2.200 mm
Table speeds, stepless: 2,5-250 rpm
Table load capacity: 20.000 kg
Table motor: 80 kW
Ram 180 x 200 mm, stroke: 1.000 mm
Live spindle...
