Rapid Feeds (X, Z Axis) 30 m/min
Rapid Feed (Y Axis) 15 m/min,
Axis Acceleration 1g
Max Speed of the Head 4.000 rpm
Ø Spindle Bar Diameter 66 mm.
Chuck Bore Ø 66 mm.
Spindle Max. Power 35 kW
Number of positions of Driven tools 16
Driven Tools Speed 4.000 rpm
Max Power Driven Tools 16 kW
Max Torque Dirven Tools 75 Nm
Coolant Tank Capacity 300 l.
Installed Power 45 KVA
Machine Weight 7.200 Kg.
Machine Dimensions 2.803×2.020×2.236 mm,.
