MACHINE INFORMATION AND SPECIFICATION

  • Manufacturer:
  • XYZ
  • Model:
  • Used XYZ XL730 x 5 Metre Gap Bed CNC Lathe (4565)
  • Condition:
  • Used
  • YOM:
  • 2021
  • Control:
  • Siemens 828D ShopTURN
  • Price:
  • POA
  • Country:
  • United Kingdom

DESCRIPTION

Used XYZ XL730 x 5 Metre Gap Bed CNC Lathe, 2021, s/n XYZ-C0-068C, Siemens 828D ShopTURN Control, Swing over bed 730mm, Swing over cross slides 510mm, Maximum turning Diameter 730mm, Cross travel 505mm, Distance between centres 5,000mm, Spindle bore 104mm, Spindle nose D1-8, Spindle power 25HP, Spindle speed 50 to 1,500rpm - 2 ranges, 635mm 4-Jaw Chuck, Indexing Toolpost, Tailstock, Tailstock quill 5MT, Swarf Conveyor, Footprint 7,700 x 2,500 x 1,730mm tall, weight 7,800kgs.
