FPT
09736
Hydrostatic guideway
CNC Heidenhain TNC 530
TRAVEL:
X mm 20.000
Y mm 1.500 (ram)
Z mm 5.000
W mm 900 (quill)
Boring quill diameter mm 160
Spindle nose ISO 50
Max spindle speed 3.000 rpm
Spindle motor power 68 KW (S6)
Max spindle torque 2450...
ANNO: 1990
C.N. SELCA 1200
Tavola girevole: 1200 x 1000 mm a 4 posizioni
Corse:
Asse X 1500 mm
Asse Y 1000 mm
Asse W 1000 mm
Asse Z 500 mm
Mandrino: ISO 50 DIN 2080
Velocità 1300 giri/min
DATI NON IMPEGNATIVI DA VERIFICARSI
SAN ROCCO
07749
CNC ECS 4801
Axis X 3100 mm
Axis Y 2000 mm
Axis Z 1600 + 600 mm at the table center
Axis W (spindle stroke) 600 mm
Axis B (Rotary table) continuous
Table 1300 x 1100 mm
T slots n.7 distance mm 160 22 H7
Load on table 5.000 kg
Horizont...
