ANNO: 200 8
Matricola: 529161503
C.N. MAZATROL 640M
Corse:
Asse X 1020 mm
Asse Y 510 mm
Asse Z 460 mm
Mandrino: ISO 40
Velocità 12000
Peso: 7700 Kg
DATI NON IMPEGNATIVI DA VERIFICARSI
EQUIPPED WITH:
Coolant
T-Slot Table
Work Clamp
Work Light
SPECIFICATIONS:
Cutting Wheel Diameter: 12"
Drive Motor HP: 3
Cutting Wheel Speed (RPM): 4500
Sectioning Capacity: 12-1/2"
Approximate Dimensions (W x D x H): 25" x 36" x 72"
Electri...
STANKOIMPORT
TRN.PAM.O443
HEIGHT OF CENTER mm. 350
MAX DIAMETER SWING OVER BED mm. 700
MAX DIAMETER SWING OVER CROSS CARRIAGE mm. 360
DISTANCE BETWEEN CENTRE mm. 1500
BED WIDTH: MM 600
BAR PASSAGING MM 80
SPINDLE SPEED N°24, RPM 10-1250
OVERALL SIZE...
ZPS
08522
VERTICAL
CNC SELCA S3045P with handwheel Selbox S2
TABLE:
Table dimensions with T-slots mm 1270x590
Max table load Kg 900
STROKES:
Axis X stroke mm 1016
Axis Y stroke mm 610
Axis Z stroke mm 760
Distance spindle center - column mm 635
Dista...
