MACHINE INFORMATION AND SPECIFICATION

  • Manufacturer:
  • LORENZ
  • Model:
  • 017836 - LORENZ LS 250
  • Condition:
  • 1
  • YOM:
  • NA
  • Control:
  • NA
  • Price:
  • POA
  • Country:

DESCRIPTION

Module from: 1.
up to: 1200 c/min.
Max. wheel diameter: 250 mm.
Max. gear cutting width: 70 mm.
Table diameter: 320 mm.
Drill diameter of the table: 125 mm.
Max. ram stroke: 100 mm.
from: 100 c/min.
Taper in ram: 40 ISO.
Voltage 50 Hz 3x: 380 Volt.
Drive: 36 kW.
Machine's weight about: 10000 kg.
Length: 4500 mm.
Width: 3200 mm.
Height: 2900 mm.
Retrofited control: 2019.
