SASS
07295
Drilling diameter mm 120
Lenght arm mm 3500
Vertical travel mm 1430
Max angle rotation 360 degree
Spindle diameter mm 135
Spindle stroke mm 600
Spindle speed n.24 Rpm 60-2650
Head power KW 18,5
Weight kg 21000
RECONDITIONED USED MACHINE
KIHEUNG
06971
BED TYPE
CNC HEIDENHAIN iTNC 530
TABLE:
-Table dimensions mm 3600x900
-T-slots (n.xwidth) 6x22H7
-Distance between T-slots mm 125
-Max table load kg 13.000
STROKE:
-Longitudinal stroke mm 3100
-Cross stroke mm 1000
-Vertical stroke mm 1...
