Max Stroke
355 mm (14”)
Strokes per min
12-110
6 Speeds
Largest shaft admitted under ram
50mm (2”)
TABLE
355 x 254mm (14 x 10”) Top Surface
283 x 295mm (11 1/8 x 11 5/8”) Side Surface
403mm (15 7/8”) Maximum table to ram...
PRELIMINARY SPECIFICATIONSNEW IN 1981MODEL G-18 (#3)40,000 RPM GRINDING SPINDLE- 60,000 RPM SPINDLE ALSO AVAILABLE19" TRAVEL LONGITUDINAL11" TRAVEL CROSS11" X 24" TABLE2" MIN FROM TABLE TO SPINDLE18" MAX FROM TABLE TO SPINDLE40-250 RPM HEAD ROTATION...
