Specification
Working Length: 3100 mm (122")
Max. Press Force: 1600 kN (176 US Tons)
Standard Stroke: 7.9"
Max. Stroke: 300 mm (11.81")
Open Height: 18.9"
Distance between Side Frames: 96.5"
Throat: 15.8"
Rapid Approach: 425 in/min
Working Speed: 1-1...
FPT
09736
Hydrostatic guideway
CNC Heidenhain TNC 530
TRAVEL:
X mm 20.000
Y mm 1.500 (ram)
Z mm 5.000
W mm 900 (quill)
Boring quill diameter mm 160
Spindle nose ISO 50
Max spindle speed 3.000 rpm
Spindle motor power 68 KW (S6)
Max spindle torque 2450...
