Maximum grinding amount: 0.099"
Maximum/Minimum tool diameter: 6.299 (type E, 4.5"
die) 0.059"
Maximum/Minimum tool height: 5.906" (With Type E
Shear-Angled Punch Body
is Used/ Chuck Jaw
Height
Standard grinding wheel dia.: 5.315"
Spindle motor:...
Max dia ground with new wheel 356mm. Max grinding length between centres 686mm. Centre height table top to centres 177mm. Table swivel included angle (clockwise) 16°. Table swivel included angle (counter clockwise) 18°. Variable speed of workhead...
STANDARD CATALOG SPECIFICATIONS18" X 20" TABLE AREA3-3/4"VERTICAL ADJUSTMENT OF TABLE10 DEGREES TILT OF TABLE, FORWARD AND BACKWARD1/4"x2-1/2"WHEEL CAPACITY10,000 RPM SPINDLE SPEEDS43"FLOOR TO TOP OF TABLEELECTRICS2 HP MAIN LOWER MOTOR/1 HP UPPER SPI...
