PRELIMINARY SPECIFICATIONSACCURPRESS HYDRAULIC PRESS BRAKE WITH 2 AXIS BACK GAUGEMODEL 717512YEAR 1996175 TON CAPACITY12 OVERALL LENGTH OF BED & RAM (144")10-4" DISTANCE BETWEEN HOUSINGS (124")8" STROKE OF RAM14" OPEN HEIGHT6" CLOSED HEIGHT10" DEPTH ...
Capacity: 80 ton
V – Ring nominal force: 3 - 25 ton
Counter ram nominal force: 0,3 - 22 ton
Ejector Force: 2 - 4 ton
Ram stroke: 50 mm
Table stroke hydraulic max.: 12 mm
Ejector stroke in ram: 8 mm
Ram surface: 420 x 420 mm
Table...
Pressure total: 50 ton
Stroke: 150 mm
Daylight: 450 mm T
able surface area : 530 x 410 mm
Slide area: 510 x 290 mm
Required power: 5,5 kW
Weight of machine approx.: 5 ton
Standard configuration: Machine was rebuilt electrical in 2006...
